Spray Booths

All spray enclosures are built to order and are available in custom sizes. Our equipment is designed to meet your business needs and conforms with OSHA and NFPA requirements. The overall size = 12'-4"W x 7'-2"T x 10'-4" and the working area = 11'-8"W x 7't x 7'D. The fan size = 24" with 2hp 3 phase TEFC (single phase optional) and all panels are constructed from 18ga, g90 galvanized steel.

All spray enclosures are built to order and all booths are Available in custom sizes. Designed to meet your business needs and conforms with OSHA and NFPA Requirements The overall size is = 10'w x 7'-2"t x 9'8"d and the Working area = 9'-8" x 7"t x 7"d. The fan size = 24" with 2 hp 3 phase TEFC (single phase optional) And all panels are constructed from 18ga, g90 galvanized steel.

Or spray enclosures are designed for powder and are plug and play, They come with one set of filters, light, control panel and a lot of money making potential. for further information please contact us and will be happy to assist you.

Working Area = 44" w x 48" t x 24" d with an overall Size = 48" w x 7'-2" h x 42" d The Fan Size is 12"3/4 hp single phase TEFC and motor 115/220v with powder coated finish. it is Constructed of 18ga g90 galvanized steel For durabilty and extended use

Units built to order and built in compliance with OSHA and NFPA. We CAN CUSTOM BUILD ANY SIZEand the working area = 44" w x 36" t x 24" d and overall Size is = 48" w x 6'-2" t x 48" d. The Fan Size is = 12" 3/4 hp single phase TEFC motor 115/220v. This uniot does come assembled although you will need to install the fan that is included and install a control panel.
