CFP 640 Fire Suppression Unit - Vertical Install, 672 Cu Ft Coverage

The CFP 640 Fire Suppression Unit is designed to bridge the gap between small-space and mid-size fire suppression applications. This vertically mounted dry chemical system protects enclosed spaces up to 8.2' x 8.2' x 10' (672.4 ft³), making it ideal for modular structures, portable shelters, storage rooms, Conex containers, and other enclosed environments requiring automatic fire protection.

The system uses CF-33 dry chemical agent, which is non-corrosive, non-conductive, and non-toxic, making it suitable for a wide range of equipment and enclosure applications. The unit automatically activates through a sprinkler head rated at 155°F (68°C) and discharges its contents throughout the protected area in less than 10 seconds.

When equipped with an optional pressure switch, the system can send a signal upon discharge to activate alarms or other connected accessories.

Features:

• Automatic dry chemical fire suppression system
• Vertical installation design
• Protects spaces up to 672.4 ft³
• CF-33 dry chemical agent
• Non-corrosive, non-conductive, and non-toxic
• Standard activation at 155°F (68°C)
• Full discharge in less than 10 seconds
• Optional pressure switch for alarm activation
• Suitable for modular spaces, storage rooms, shelters, and Conex containers
• High-purity compressed dry nitrogen propellant
• UL Listed

Specifications:

• Maximum Flood Volume: 8.2' x 8.2' x 10' = 672.4 ft³ (18.91 m³)
• Reach Coverage Area: 8.20' x 8.20' = 64.24 ft² (6.25 m²)
• Temperature Rating: -20°F to 120°F (-29°C to 49°C)
• Cylinder: Worthington
• Diameter: 7.50" (19.05 cm)
• Height: 11.38" + 3.50" Coupling Assembly
• Capacity: 7 lbs (3.18 kg)
• Unit Weight: 19.25 lbs (8.73 kg)
• Shipping Weight: 23.25 lbs (10.55 kg)
• Propellant: High-Purity Compressed Dry Nitrogen
• Standard System Activation: 155°F (68.3°C)

Approvals:

• UL Listed
• ULC Approved
• CSFM Approved
• NYC Approval #5754

Shipping: Standard lead time 4-5 weeks (custom-built per order). Rush: 2-3 weeks. Expedited Rush: 1 week or sooner. Contact us for rush pricing.
